FOX Performance Elite Series 2.5 improve the LC300 and LX600 chassis by eliminating the vehicle’s forward rake, providing a level ride height, and increasing the suspension articulation. Type III anodization prevents corrosion and wear of the 2.5-inch aluminum bodies. External reservoirs increase oil capacity and decrease the harshness associated with nitrogen ramp-up. Each reservoir features a Dual Speed Compression Evolution (DSC EVO) adjuster strategically mounted to eliminate interference with aggressive tires at full lock. DSC EVO features Variable Valve Control (VVC) on the high-speed circuit. VVC doesn't add preload to the shim stack to adjust high-speed damping. The result is more comfort, independent high and low-speed circuits, and increased capacity for big hits. Add clicks of highspeed compression without sacrificing small-bump sensitivity. Performance Elite shocks with DSC EVO provide versatility without compromise to navigate rough terrain and enhance on-road manners while remaining comfortable and in control.



SPECS:

PART NUMBER	883-06-240
FEATURES	2.5" impact-extruded and CNC-machined 6061-T6 Type III anodized aluminum body 7/8" hard chromed steel shafts Vehicle-specific tuning maximizes performance Redundant sealing pack system: main seal, wiper seal, scraper seal External reservoir, with DSC EVO adjuster
SERIES	Performance Elite
TRAVEL	6.67
BODY	2.5" Impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
BODY PLATING	Hard-anodized for a durable finish
COMPONENTS	Black-anodized, CNC-machined 6061-T6 billet aluminum
SHAFT	7/8" hard chrome plated steel shafts
PISTON	6061-T6 hard-anodized, high flow aluminum piston
VALVING	"Heavy Duty" tune for higher payload applications
EXTENDED LENGTH	24.98
COMPRESSED LENGTH	18.31
TOP MOUNT	OEM
BOTTOM MOUNT	Eyelet
FITMENT NOTES	Heavy Duty version designed for additional payload
